| Chassis | |
| Frame: | Downhill frame with COR design (Centered on Rider) and 27.5" specific geometry, 6069er T6 aluminum, 210mm travel via independet drivetrain system, 1.5" head tube, ISCG03 chain guide mount, 12 x 150mm thru axle |
| Fork: | FOX Factory 40 Float 27.5, air suspension system (adjustable), 203mm travel, 20 x 110mm thru axle, adjustable rebound and high-/low-speed compression |
| Shock: | FOX Float X2, adjustable rebound and high-/low-speed compression, bottom-out |
| |
| Drivetrain/Brakes | |
| Shifters: | Shimano Saint, 10-speed |
| Rear derailleur: | Shimano Saint Shadow+, direct mount |
| Chain guide: | e.thirteen LG1+ with bash guard |
| Crankset: | Shimano Saint, 36 teeth chain ring, 165mm length |
| Bottom bracket: | Shimano Saint, 83mm housing |
| Pedals: | - |
| Chain: | Shimano CN-HG95 |
| Cogs: | Shimano Ultegra (CS-6700), 10-speed, 11-25 teeth |
| Brakes: | Shimano Saint (BR-M820), hydraulic disc brakes, 203mm Centerlock IceTech discs (f/r) |
| Brake levers: | Shimano Saint (BL-M820) |
| |
| Wheels | |
| Front hub: | Shimano Saint (HB-M820), 20 x 110mm thru axle, Centerlock mount |
| Rear hub: | Shimano Saint (FH-M825), 12 x 150mm thru axle, Centerlock mount |
| Rims: | Stan's NoTubes Flow MK3 27.5", 32 hole |
| Tires: | Schwalbe Magic Mary, 27.5 x 2.35" (f/r) |
| |
| Components | |
| Stem: | Race Face Atlas, direct mount, 30/50mm length, 31,8mm diameter |
| Handlebar: | Race Face Atlas, 1.5" rise, 785mm width, 31,8mm diameter |
| Headset: | FSA Orbit Z 1.5R, 1.5" >>> 1 1/8" reducer headset, sealed bearings |
| Saddle: | WTB Silverado Pro, cromoly rails |
| Seat post: | Race Face Turbine, 31,6 x 400mm |
| Other: | - |
