| Chassis | |
| Frame: | New Grade aluminum frame with triple triangle design, hydroformed top and down tube, wide tire clearance (up to 35mm), tapered head tube, standard bottom bracket housing |
| Fork: | Grade carbon with 1 1/4" - 1 1/8" carbon steerer |
| Shock: | - |
| Drivetrain/Brakes | |
| Shifters: | SRAM Force, 1 x 11-speed |
| Rear derailleur: | SRAM Force |
| Front derailleur: | - |
| Crankset: | SRAM Force, 40 teeth chain ring |
| Bottom bracket: | SRAM GXP |
| Pedals: | - |
| Chain: | KMC X11 |
| Cogs: | SRAM, 11-speed, 11-28 teeth |
| Brakes: | SRAM Force, hydraulic disc brakes, 160mm centerline discs (f/r) |
| Brake levers: | SRAM Force |
| Wheels | |
| Front hub: | Formula, sealed bearings, 32 hole, quick release |
| Rear hub: | Formula, sealed bearings, 32 hole, quick release |
| Rims: | Stan's No Tubes Radler Disc |
| Tires: | Clement 10039, 60 TPI, 700 x 33 (f/r) |
| Components | |
| Stem: | GT road design, 3D-forged 6061 aluminum, 4 bold clamp |
| Handlebar: | GT DropTune Super Light, double butted 6061 aluminum |
| Headset: | TH integriert, sealed bearings |
| Saddle: | Fizik Monte, magnesium rails |
| Seat post: | Aluminum |
| Other: | - |
| Table of geometry | click here |
Product video:
Video of the Grade series:
| Model year | 2017 |
| Intended use | Road |
| Wheel size | 28" |
| Frame material | Aluminum |
| Shifting type | Derailleur |
| Gears | 11 |
